STEDI - ST3K 21.5 INCH 20 LED SLIM LED LIGHT BAR
OVERVIEW
The STEDI ST3K LED Light Bar was designed to bring a large amount of light to a small amount of space. With its small profile of just 63mm total height with the side brackets attached, you will find the ST3K is able to be mounted in locations like your front bar and grill whilst maintaining the factory look of your vehicle.
PERFORMANCE
The ST3K packs quite a powerful punch running off the same Pure Drive technology + LEDs as the popular Type-X and ST4K range. Ability to mount in tight spaces are its key trait as it can be mounted on your standard vehicle and prove to be a useful source of light whilst driving out bush with cars that don't have the space to run some of our larger LED light bars.
BEAM CHARACTERISTICS
Easily comparable to the STEDI Type-X and ST4K range the beam type of the ST3K follows in line. Providing a strong penetrating beam with 493m at 1 LUX and 55m out to the shoulders of the road with flood beam, the perfect all-rounder with low profile has arrived!
MARKET LEADING PERFORMANCE
ST3K-20L features 20 of OSRAM’s® finest OSLON® LED, selected for unrivalled efficiency.
4 Flood + 12 Spot + 4 Flood reflector distribution forms a remarkable beam that pushes the wide beam out at 50° and spot beam at 5.8° all the way to staggering 1 lux @ 493m
True White 5700K Colour temperature offers stunning clarity and definition.
Pure-Drive™ circuit design allow 97% of input power to go directly to LEDs.
BUILT TO WITHSTAND THE RELENTLESS PUNISHMENT OF THE DEEP AUSTRALIAN OUTBACK
Finished in 100% Polyester UV and abrasion resistant powder coat, ensures that Stedi bars will never discolour.
Pressure Equalization vent | Protects against water ingress, dust & contaminants.
IP68 | Dust & Particle tight + Water-proof up to 3 meters!
Environmentally sealed Deutsch ® DT-2 connector.
Protected against EMC and RFI.
Ultra-Low 51mm profile without the side brackets & 63mm with side brackets!
Includes Easy Fit High Beam Plug and Play Wiring Harness which includes H4 and HB3 Adapters making for an easy connection to high beam. Unlike the copycat harnesses on the market Stedi's has built in electronics making our harness compatible with even the most modern and sophisticated wiring systems
Backed by a Stedi 5 Year Replacement Warranty.
- Product details and blurb care of STEDI
WHAT’S IN THE BOX
ST3K 21.5inch LED LIGHT BAR
Stainless Fasteners
Stainless Steel Side Mounting Brackets
12v Quick Fit to High Beam Wiring, Relay, Wiring Kit and On/Off Switch
H4 and HB3 adapters included
Wiring Instructions
Installation is available from the Cruisemaster Towing Performance Centre (352 Bilsen Road, GEEBUNG 4034). Installs available via booking Mon - Thurs 7.30am - 4.30pm Fri 7.30am - 12.30pm.
Additional charges apply
OVERVIEW
The STEDI ST3K LED Light Bar was designed to bring a large amount of light to a small amount of space. With its small profile of just 63mm total height with the side brackets attached, you will find the ST3K is able to be mounted in locations like your front bar and grill whilst maintaining the factory look of your vehicle.
PERFORMANCE
The ST3K packs quite a powerful punch running off the same Pure Drive technology + LEDs as the popular Type-X and ST4K range. Ability to mount in tight spaces are its key trait as it can be mounted on your standard vehicle and prove to be a useful source of light whilst driving out bush with cars that don't have the space to run some of our larger LED light bars.
BEAM CHARACTERISTICS
Easily comparable to the STEDI Type-X and ST4K range the beam type of the ST3K follows in line. Providing a strong penetrating beam with 493m at 1 LUX and 55m out to the shoulders of the road with flood beam, the perfect all-rounder with low profile has arrived!
MARKET LEADING PERFORMANCE
ST3K-20L features 20 of OSRAM’s® finest OSLON® LED, selected for unrivalled efficiency.
4 Flood + 12 Spot + 4 Flood reflector distribution forms a remarkable beam that pushes the wide beam out at 50° and spot beam at 5.8° all the way to staggering 1 lux @ 493m
True White 5700K Colour temperature offers stunning clarity and definition.
Pure-Drive™ circuit design allow 97% of input power to go directly to LEDs.
BUILT TO WITHSTAND THE RELENTLESS PUNISHMENT OF THE DEEP AUSTRALIAN OUTBACK
Finished in 100% Polyester UV and abrasion resistant powder coat, ensures that Stedi bars will never discolour.
Pressure Equalization vent | Protects against water ingress, dust & contaminants.
IP68 | Dust & Particle tight + Water-proof up to 3 meters!
Environmentally sealed Deutsch ® DT-2 connector.
Protected against EMC and RFI.
Ultra-Low 51mm profile without the side brackets & 63mm with side brackets!
Includes Easy Fit High Beam Plug and Play Wiring Harness which includes H4 and HB3 Adapters making for an easy connection to high beam. Unlike the copycat harnesses on the market Stedi's has built in electronics making our harness compatible with even the most modern and sophisticated wiring systems
Backed by a Stedi 5 Year Replacement Warranty.
- Product details and blurb care of STEDI
WHAT’S IN THE BOX
ST3K 21.5inch LED LIGHT BAR
Stainless Fasteners
Stainless Steel Side Mounting Brackets
12v Quick Fit to High Beam Wiring, Relay, Wiring Kit and On/Off Switch
H4 and HB3 adapters included
Wiring Instructions
Installation is available from the Cruisemaster Towing Performance Centre (352 Bilsen Road, GEEBUNG 4034). Installs available via booking Mon - Thurs 7.30am - 4.30pm Fri 7.30am - 12.30pm.
Additional charges apply
OVERVIEW
The STEDI ST3K LED Light Bar was designed to bring a large amount of light to a small amount of space. With its small profile of just 63mm total height with the side brackets attached, you will find the ST3K is able to be mounted in locations like your front bar and grill whilst maintaining the factory look of your vehicle.
PERFORMANCE
The ST3K packs quite a powerful punch running off the same Pure Drive technology + LEDs as the popular Type-X and ST4K range. Ability to mount in tight spaces are its key trait as it can be mounted on your standard vehicle and prove to be a useful source of light whilst driving out bush with cars that don't have the space to run some of our larger LED light bars.
BEAM CHARACTERISTICS
Easily comparable to the STEDI Type-X and ST4K range the beam type of the ST3K follows in line. Providing a strong penetrating beam with 493m at 1 LUX and 55m out to the shoulders of the road with flood beam, the perfect all-rounder with low profile has arrived!
MARKET LEADING PERFORMANCE
ST3K-20L features 20 of OSRAM’s® finest OSLON® LED, selected for unrivalled efficiency.
4 Flood + 12 Spot + 4 Flood reflector distribution forms a remarkable beam that pushes the wide beam out at 50° and spot beam at 5.8° all the way to staggering 1 lux @ 493m
True White 5700K Colour temperature offers stunning clarity and definition.
Pure-Drive™ circuit design allow 97% of input power to go directly to LEDs.
BUILT TO WITHSTAND THE RELENTLESS PUNISHMENT OF THE DEEP AUSTRALIAN OUTBACK
Finished in 100% Polyester UV and abrasion resistant powder coat, ensures that Stedi bars will never discolour.
Pressure Equalization vent | Protects against water ingress, dust & contaminants.
IP68 | Dust & Particle tight + Water-proof up to 3 meters!
Environmentally sealed Deutsch ® DT-2 connector.
Protected against EMC and RFI.
Ultra-Low 51mm profile without the side brackets & 63mm with side brackets!
Includes Easy Fit High Beam Plug and Play Wiring Harness which includes H4 and HB3 Adapters making for an easy connection to high beam. Unlike the copycat harnesses on the market Stedi's has built in electronics making our harness compatible with even the most modern and sophisticated wiring systems
Backed by a Stedi 5 Year Replacement Warranty.
- Product details and blurb care of STEDI
WHAT’S IN THE BOX
ST3K 21.5inch LED LIGHT BAR
Stainless Fasteners
Stainless Steel Side Mounting Brackets
12v Quick Fit to High Beam Wiring, Relay, Wiring Kit and On/Off Switch
H4 and HB3 adapters included
Wiring Instructions
Installation is available from the Cruisemaster Towing Performance Centre (352 Bilsen Road, GEEBUNG 4034). Installs available via booking Mon - Thurs 7.30am - 4.30pm Fri 7.30am - 12.30pm.
Additional charges apply
SPECIFICATIONS
RAW LUMENS: 9,800Lm
LED: 20 x Osram Oslon White
PEAK INTENSITY: 243,200cd
OPERATING VOLTAGE: 10-30V DC
CURRENT DRAW: 4.3A @ 13.5v
IP RATING: IP 68
COLOUR TEMP (CCT): 5700K
BEAM TYPE: Flood Spot Combo
LENS: GE Lexan
MATERIAL: Die Cast Aluminium with Extruded heat-sink
MOUNTING BRACKET: Powder Coated 3mm Stainless Steel
BOLTS AND FITTINGS: 3 Series Stainless Steel
LIFE SPAN: 50,000 Hours
WEIGHT: 1.855KG
STEDI P/N: LEDST3K-20L
